EIS Wire & Cable has extensive experience furnishing the Audio Broadcast markets with custom cable products to meet their demanding specifications. Our Speaker, Guitar, Snake and Microphone cables have earned a reputation for performance on par with the industry’s most recognizable brand names. Our superior customer service combined with our fast lead times make EIS Wire an ideal option for your custom or private label needs.
Benefits:
Applications:
Typical Design Options - Guitar Cable
Single Conductor
18 awg – 24 awg Annealed Bare Copper or Tinned Copper
Solid or Bunched Stranded Copper
(Oxygen Free Bare Copper or Silver Plated Copper available)
Insulation
High Density or Low Density Polyethylene (Foamed or Solid)
Shielding
Semi Conductive PVC to minimize Triboelectric noise
Tinned or Bare Copper, Spiral or Full Braid Shield
(with varying coverage based on your specification / needs)
Jacket
Flexible PVC Jackets with matte finish
Standard Color: Black
(Custom Colors Available Upon Request)
Packaging
Wood Reels or Spools
Standard Put-up: 1,000 ft reels
Bulk Put-ups are available
Benefits:
Applications:
Typical Design Options - Speaker Cable
2 – 8 Conductors
11 awg to 16 awg
Annealed Bare Copper or Tinned Copper
Bunch Stranded Copper
(Oxygen Free Copper available)
Insulation
Flexible PVC (Color Coded to Spec)
Shielding
N/A
Jacket
Flexible PVC with Matte Finish
Standard Color: Black
Custom Colors Available Upon Request
Packaging
Wood Reels or Spools
Standard Put-ups: 1,000 ft reel
Bulk Put-ups are available
Benefits:
Applications:
Typical Design Options - Microphone (Mic) and Studio Quad Cable
2 – 4 Conductors
20 awg to 26 awg
Annealed Bare Copper or Tinned Copper
Solid or Bunch Stranded Copper
(Oxygen Free Copper or Silver plated copper available)
Insulation
Flexible PVC (Color Coded to Spec)
Polypropylene (Foamed & Solid)
High Density or Low Density Polyethylene (Foamed or Solid)
Shielding
Semi Conductive PVC to minimize Triboelectric noise
100% Aluminum Mylar – 25 % Overlap
Tinned or Bare Copper, Spiral or Full Braid Shields
(with varying coverage based on your specification / need)
Jacket
Flexible PVC or TPE Jackets with Matte Finish
Standard Color: Black
Custom Colors Available Upon Request
Packaging
Wood Reels or Spools
Standard Put-ups: 1,000 ft reel
Bulk Put-ups are available
Benefits:
Applications:
Typical Design Options - Snake Cable
2 – 112 Conductors
1-Channel, 2-Channel, 4-Channel,
8-Channel, 12-Channel, 16-Channel
24-Channel, 28-Channel, 32-Channel,
48-Channel, 56-Channel
24 awg to 26 awg
Annealed Bare Cpper or Tinned Copper
Bunch Stranded Copper
(Oxygen Free Copper available)
Other Channel Configurations available upon request
Insulation
Polypropylene (Foamed & Solid)
High Density Polyethylene (Foamed or Solid)
(Color Coded to Spec)
Shielding
100% Aluminum Mylar – 25 % Overlap
Tinned or Bare Copper, Spiral or Full Braid Shields
(with varying coverage based on your specification / need)
Jacket
(Inner Pairs and Outer Jacket)
Flexible PVC or TPE Inner Pairs and/or Outer Jacket with Matte Finish
Standard Color: Black
Custom Colors Available Upon Request
Packaging
Wood Reels or Spools
Standard Put-ups: 1,000 ft reel
Bulk Put-ups are available
Contact us today to see how we can meet your specific requirements.
